BK2000 Series Biological Microscope
|
Description:
|
|
Total magnifications ............................40X-1600X
Eyepiece ................................................WF10X
S-Plan achromatic objectives
..................... 4/0.10 10/0.25 40/0.65 100/1.25(Oil)
Condenser ...........................................N.A. 1.25
Coaxial coarse and fine focusing adjustment knobs
Base
Built in 6V 20W halogen bulb with adjustable brightness
Optional accessories
1) Eyepieces .......WF16X WF10X(pointer) WF10X(reticle)
2) Photo eyepieces..................................S2.5 S4
3) Phase contrast attachment
4) 35mm photo attachment
5) C-Mount and CCD camera
6) Simple polarizer attachment ........Polarizer slide
.....................................................Analyzer slide
7) Dark field attachment .........Dark field condenser
|
BK2000 Standard Outfits
|
Item
|
Specification
|
Bk2100
|
Bk2200
|
Bk2201
|
Bk2300
|
Bk2301
|
Order No.
|
|
Eyepieces
|
Plan eyepiece(10X-18)
|
●
|
●●
|
●●
|
●●
|
●●
|
EP10a
|
|
Photo negative eyepiece S4
|
|
|
|
●
|
●
|
EPHn4
|
|
Achromat
objectives
|
4/0.10
|
●
|
|
|
○
|
○
|
B-OA4c
|
|
10/0.25
|
●
|
|
|
○
|
○
|
B-OA10d
|
|
(S)40/0.65
|
●
|
|
|
○
|
○
|
B-OA40d
|
|
(S)100/1.25 oil
|
●
|
|
|
○
|
○
|
B-OAo100c
|
|
Plan objectives
|
SPlan 4/0.10
|
○
|
●
|
●
|
●
|
●
|
B-OSPr4
|
|
SPlan 10/0.25
|
○
|
●
|
●
|
●
|
●
|
B-OSPr10
|
|
SPlan 40/0.65
|
○
|
●
|
●
|
●
|
●
|
B-OSPr40
|
|
SPlan(S) 100/1.25(oil)
|
○
|
●
|
●
|
●
|
●
|
B-OSPor100
|
|
Eyepiece
Heads
|
Monocular head (45°inclined,
360°circumrotation)
|
●
|
|
|
|
|
TM18
|
|
Teaching head
|
○
|
○
|
○
|
|
|
TM16
|
|
Binocular head
(45°inclined,slide)
|
|
●
|
|
|
|
TB10
|
|
Trinocular head
(45°inclined,slide)
|
|
|
|
●
|
|
TT05
|
|
Binocular head
(30°inclined,revolution)
|
|
|
●
|
|
|
TBR06
|
|
Trinocular head
(30°inclined,revolution)
|
|
|
|
|
●
|
TTR02
|
|
Main Body
|
Five-hole nosepiece (built-in)
|
|
●
|
●
|
●
|
●
|
MSBk4
|
|
Four-hole nosepiece (built-in)
|
●
|
○
|
○
|
○
|
○
|
MSBk3
|
|
Condenser
|
N.A.1.25Oil
|
●
|
●
|
●
|
●
|
●
|
C20
|
|
Base
|
AC220V or 110V
|
●
|
●
|
●
|
●
|
●
|
B26
|
|
atachment
|
35mm DF camera
|
|
|
|
●
|
●
|
|
|
Photo tube
|
|
|
|
●
|
●
|
MP03
|
|
Immersion oil
|
|
●
|
●
|
●
|
●
|
●
|
|
|
Filter
|
￠32 (blue)
|
●
|
●
|
●
|
●
|
●
|
CU02-1
|
|
CCD attachment
|
|
|
|
|
○
|
○
|
TV02
|
BK2000 Optional Accessories
|
Item
|
Specification
|
Order No
|
|
Eyepieces
|
Plan eyepiece (16X-10)
|
EP16a
|
|
Pointer eyepiece (10X-17.2)
|
Erg10
|
|
Plan reticle eyepiece (10X-18)
|
EPr10b
|
|
2.5X photo negative eyepiece
|
EPHn2.5
|
|
Achromatic
Phase-contrast
attachment
|
8X Central eyepiece
|
EC8
|
|
Achromatic negative phase-contrast objective 10/0.25
|
B-OAn10
|
|
Achromatic negative phase-contrast objective 40/0.65
|
B-OAn40
|
|
10x annular plate
|
RP01
|
|
40x annular plate
|
RP02
|
|
Plan
phase-contrast
attachment
|
Plan achromatic negative phase-contrast
objective SPlan10/0.10
|
B-OSPnr10a
|
|
Plan achromatic negative phase-contrast
objective SPlan (S)40/0.10
|
B-OSPnr40a
|
|
Plan achromatic negative phase-contrast
objective SPlan (S)100/1.25
|
B-OSPonr100
|
|
Plan achromatic positive phase-contrast
objective SPlan10/0.10
|
B-OSPpr10
|
|
Plan achromatic positive phase-contrast
objective SPlan (S)40/0.65
|
B-OSPpr40
|
|
Plan achromatic positive phase-contrast
objective SPlan (S)100/1.25
|
B-OSPopr100
|
|
Phase-contrast condenser (used in SPlan phase-contrast
Objective)
|
C06a
|
|
Field diaphragm
|
|
DI06
|
|
Filter
|
￠32 (Green)
|
CU02-2
|
|
￠32 (Amber)
|
CU02-3
|
|
Relector
|
|
MT04
|
|
Dark field
attachment
|
Dark field condenser N.A.0.83-0.91
|
C07
|
|
Simple dark field attachment
|
DS03
|
|
Simple polarizer
attachment
|
Polarizer slide
|
PO01
|
|
Analyzer
|
PA01
|
Note：“●”in the table is standard attachment. “○”is optional accessories.
Design change:To keep pace with technological advance ,we have reserved
the right to make design modifications and changes without notice.
