Environmental Stress-Cracking Test Apparatus TBT1440

Item Code:TBT1440 Features:
  • Description
  • Referring Standard
  • Features
  • Technical Specification

Application:Used to determine the susceptibility of ethylene colophony and plastics to environmental stress crack under specified conditions.

Standards:GB/T1842-2008,GB/T2951.41-8-2008,IEC60811-4-1-2004,ASTM D1693-2008,etc.

Model No.

TBT1440

Number of working position

9

Temperature range

RT~90℃

Temperature accuracy

±0.5℃

Specimen specification

(38±2)×(13±1)×(1.5~3.5)mm(L×W×T)

Notch depth

0.2~0.8mm

Adjustable
