BK1000 Series Biological Microscope
Description:
|
Total magnifications ..............................40X-1600X
Eyepiece ..................................................WF10X
Achromatic objectives ..........4/0.10 10/0.25 40/0.65
........................................................ 100/1.25(Oil)
Condenser ................................................NA1.25
Coaxial coarse and fine focusing adjustment knobs
Base ....Built in 6V 20W halogen bulb with adjustable brightness
Optional accessories
1) Eyepieces .....................WF16X WF10X (article )
2) Photo eyepiece ..........................S2.5X S4X 6.3X
3) S-Plan achromatic objectives
........................ 4/0.10 10/0.25 40/0.65 100/1.25(Oil)
4) Plan achromatic objectives
.............. 4/0.10 10/0.25 25/0.4 40/0.65 100/1.25(Oil)
5) Dark field attachment.............Dark field condenser
6) Simple polarizer attachment ...........Polarizer slide
........................................................Analyzer slide
7) Phase contrast attachment
8) 35mm photo attachment
9) C-Mount and CCD camera
|
Standard Outfits
Order No.
|
Items
|
BK1200
|
BK1201
|
BK1300
|
BK1301
|
EP10a
|
Eyepiece WF 10×/¢18
|
●●
|
●●
|
●●
|
●●
|
B-OA4c
|
Achromat Objective 4×/0.10
|
●
|
●
|
○
|
○
|
B-OA10d
|
Achromat Objective 10×/0.25
|
●
|
●
|
○
|
○
|
B-OA40d
|
Achromat Objective (S)40×/0.65
|
●
|
●
|
○
|
○
|
B-OAo100c
|
Achromat Objective (S)100×/1.25(Oil)
|
●
|
●
|
○
|
○
|
B-OSPr4
|
S-Plan Achromat Objective 4×/0.10
|
○
|
○
|
●
|
●
|
B-OSPr10
|
S-Plan Achromat Objective 10×/0.25
|
○
|
○
|
●
|
●
|
B-OSPr40
|
S-Plan Achromat Objective (S)40×/0.65
|
○
|
○
|
●
|
●
|
B-OSPor100
|
S-Plan Achromat Objective (S)100×/1.25(Oil)
|
○
|
○
|
●
|
●
|
TB10
|
Sliding Binocular Head (Inclined 45°)
|
●
|
○
|
○
|
○
|
TT05
|
Sliding Trinocular Head (Inclined 45°)
|
○
|
○
|
●
|
○
|
TBR06
|
Seidentopf Binocular Head (Inclined 45°)
|
○
|
●
|
○
|
○
|
TTR02
|
Sliding Trinocular Head (Inclined 30°)
|
○
|
○
|
○
|
●
|
MSbk2
|
Body With Auxiliary Lens
|
●
|
●
|
●
|
●
|
C20
|
Condenser(N.A.1.25 Oil)
|
●
|
●
|
●
|
●
|
B26
|
Base (AC110V or 220V)
|
●
|
●
|
●
|
●
|
MP03
|
35mm Camera With Adaptor
|
|
|
○
|
○
|
EPHn4
|
Photo Eyepiece 4×
|
|
|
○
|
○
|
CU02-1
|
Blue Filter
|
●
|
●
|
●
|
●
|
TV02
|
CCD TV Attachment
|
|
|
○
|
○
|
Note:“●”in the table is standard attachment. “○”is optional accessories.
Design change:To keep pace with technological advance ,we have reserved
the right to make design modifications and changes without notice.
