Screw diameter

20

Rotation speed of screw

0-95 rpm

Length ratio

1:28

Main Motor

2.2KW

Screw material

38CrMoAL chromium-molybdenum steel

Volume   W×D×H

Around1250×500×940mm

Power supply

AC380V, 3 phase

Die diameter

30

Air blowing

Compressed air 0-6bar

Air cooling

Air blower flow 30L/min

Traction roller size

80*320mm

Traction winding speed

0.5-5m/min

Max film folding diameter

150mm

Traction motor

90W

Winding torque motor

3.5N.m

Fan

0.25Kw

Dimension

800X700X2050mm

Power supply

AC380V, 3 phase

Weight

215kg
