Cable Free Horizontal Fiber Optic Gyroscope Inclinometer Manufacturer

1. It adopts a high precision fiber optic gyroscope as the measuring component. Small size, long lifetime, good shock and vibration resistance. The zero drift is small. It is the magnetic area and the azimuth angle of the ideal orientation sensor measurement iron casing drilling.

2. It adopts a high precision double-shaft sensor to measure the dip angle. The dip angle data will be collected by 24 bit AD and processed.

3. Equipped with special software, it can show test data table, and plot plane diagram, sectional diagram, side projection diagram, and space trace diagram.

Measuring range	Angle: +60°～-60°
Measuring range	Azimuth: 0°～360°
Measurement accuracy	Angle measurement error: ±0.1°
Measurement accuracy	Azimuth measurement error: ±0.3° (Angle changes <± 10 °, azimuth changes <± 30 °)
The azimuth drift	< 0.3°/h
Measuring depth	1200 m (temperature <60 ℃)
Measuring time	> 5 h (It will continuous after full of power)
Measurement mode	measuring point
Charging Power	AC 100V～AC 240V，50Hz
Battery	4-core lithium battery
Ambient temperature	-10℃～60℃
Measuring probe dimensions and weight	Φ40 mm×1800 mm

Cable Free Horizontal Fiber Optic Gyroscope Inclinometer JTL-40FWL
