    Aggregate Methylene Blue Value Set TBTYJ-3

    • Aggregate Methylene Blue Value Set
    • Aggregate Methylene Blue Value Set
    Aggregate Methylene Blue Value Set
    Aggregate Methylene Blue Value Set
    Item Code:TBTYJ-3 Features:MBV Methylene Blue Value is a parameter of the amount of potentially harmful fine material such as swelling clay minerals in fine aggregates, it is a test method to determine the clay content & the cleanliness of aggregates.
    • Description
    • Main Specifications
    • Accessories

    Main Features:
    The equipment adopts advanced technology of frequency modulation & numerical control to improve the accuracy & speed of test.

    This method is suitable for measurement of fine aggregates particle smaller than 2.36mm or 0.15mm, or inspection of mineral powders.

    Specification:

    Power supply:

    AC 220V, 50HZ

    Maximum speed:

    600 ±10 revolutions

    Minimum speed:

    400±10 revolutions/min

    Impeller diameter:

    75mm±10mm

    Quantity of impellers:

    4 items

    Volume of beaker:

    1000mL

    Impeller diameter:

    75mm±10mm

    Weight:

    11 Kg

    Dimension:

    420x270x960mm

    Power consumption:

    400W

    Ambient temperature:

    ≤35°C

    Relative humidity:

    ≤85%
