X-Ray Pipeline Crawler X-PCD2000

Item Code:X-PCD2000 Features:
Neutral packing
OEM accepted
  • Description
  • Main Specifications
  • Accessories
The X-Ray pipeline crawler include the special part that can detect the welding line of long pipeline. The X-ray pipeline crawlers have the advantages of high radiographic quality, high imaging sensitivity, low failure rate and high work efficiency.
The X-ray pipeline crawlers have differential driving and vibration absorbers. The chassis of the X-ray pipeline crawlers can be moved in the pipeline steadily without off center running and overturning. The X-ray pipeline crawlers can be moved in the pipeline with great efficiency because it is controlled by PLC with protecting it from blocking and under voltage. The X-ray pipeline crawler is easy to be separated into several parts and then to be put together, so it is easy to carry. You can change the exposure parameter and make the X-ray pipeline crawler move, stop and have an exposure with the exterior controlling source. The X-ray pipeline crawlers are easy to operate.


Type
X-PCD2000-1
X-PCD2000-2
X-PCD-3
Penetration Pipe Diameter
300-1200
273-800mm
159-400mm
Formal Size
1.0*0.25m
0.85*0.2m
1.0*0.15m
Total Weight
50kg
45kg
30kg
Motor Power
12W (continuous)
120W (continuous)
80W (continuous)
Battery Power
24V 14Ah
24V 14Ah
24V 14Ah
Crawling Speed
15-18m/min
15-18m/min
15-18m/min
Crawling Slope
30°
30°
30°
Swerving Radii
5D
5D
10D
Radiative Source
Ir-192(5-100ci)
Ir-192(5-100ci)
Ir-192(5-100ci)
Se75(5-100ci)
Se75(5-100ci)
Se75(5-100ci)
Radiative Angle
45°
45°
45°
Time of Exposure
30 Minutes (continuous)
30 Minutes (continuous)
30 Minutes (continuous)
Time of Delay
30s
30s
30s
Positioning Source
200mci Cs 137
200mci Cs 137
200mci Cs 137
Crawling Distance
5Km * 2
3Km * 2
3Km * 2
Relative Humidity
< 70°
< 70°
< 70°
Environment Humidity
10-90%RH (incondensable)
10-90%RH (incondensable)
10-90%RH (incondensable)
