Table-type Digital Controlled Supersonic Cleaner (KQ Series) Manufacturer

Table-type Digital Controlled Supersonic Cleaner (KQ Series)

Item Code: Features:

Neutral packing
OEM accepted

Description
Main Specifications
Accessories

KQ Series Table-type Digital Controlled Supersonic Cleaner

Model	Size	Bath size	Capacity	Supersonic power	Power adjustable	Heating power	Temp. adjustable	Time adjustable
	L x W x H (mm)	L x W x H (mm)	(L)	(W)	(%)	(W)	(℃)	(min)
KQ- 50DA	208×192×210	150×140×100	2	50	40-99	No	No	1-99
KQ- 50DB	208×192×210	150×140×100	2	50	40-99	200	20-80	1-99
KQ- 50DE	208×192×210	150×140×100	2	50	40-99	200	20-80	1-99
KQ 2200DA	260×160×260	230×140×100	3	100	40-99	No	No	1-99
KQ2200DB	260×160×260	230×140×100	3	100	40-99	600	20-80	1-99
KQ 2200DE	260×160×280	230×140×100	3	100	40-99	600	20-80	1-99
KQ 2200DV	340×250×330	230×140×130	4	100	40-100	600	20-80	1-480
KQ- 100DA	320×174×260	300×150×100	4	100	40-100	No	No	1-480
KQ- 100DB	320×174×260	300×150×100	4	100	40-100	600	20-80	1-480
KQ- 100DE	320×174×280	300×150×100	4	100	40-100	600	20-80	1-480
KQ- 100DV	410×260×330	300×150×130	5.8	100	40-100	600	20-80	1-480
KQ 3200DA	320×174×320	300×150×150	6	150	40-100	no	No	1-480
KQ 3200DB	320×174×320	300×150×150	6	150	40-100	600	20-80	1-480
KQ 3200DE	320×174×340	300×150×150	6	150	40-100	600	20-80	1-480
KQ 3200DV	410×260×380	300×150×180	8	150	40-100	600	20-80	1-480
KQ 5200DA	320×264×320	300×240×150	10	200	40-100	No	No	1-480
KQ 5200DB	320×264×320	300×240×150	10	200	40-100	600	20-80	1-480
KQ 5200DE	320×264×340	300×240×150	10	200	40-100	600	20-80	1-480
KQ 5200DV	410×350×380	300×240×180	13	200	40-100	600	20-80	1-480
KQ- 250DA	320×264×320	300×240×150	10	250	40-100	No	No	1-480
KQ- 250DB	320×264×320	300×240×150	10	250	40-100	600	20-80	1-480
KQ- 250DE	320×264×340	300×240×150	10	250	40-100	600	20-80	1-480
KQ- 250DV	410×350×380	300×240×180	13	250	40-100	600	20-80	1-480
KQ- 300DA	320×264×320	300×240×150	10	300	40-100	No	No	1-480
KQ- 300DB	320×264×320	300×240×150	10	300	40-100	600	20-80	1-480
KQ- 300DE	320×264×340	300×240×150	10	300	40-100	600	20-80	1-480
KQ- 300DV	410×350×380	300×240×180	13	300	40-100	600	20-80	1-480
KQ- 500DA	530×320×360	500×300×150	22.5	500	40-100	No	No	1-480
KQ- 500DB	530×320×360	500×300×150	22.5	500	40-100	1000	20-80	1-480
KQ- 500DE	530×320×380	500×300×150	22.5	500	40-100	1000	20-80	1-480
KQ- 500DV	610×410×380	500×300×180	27	500	40-100	1000	20-80	1-480
KQ- 600DA	530×320×360	500×300×150	22.5	600	40-100	No	No	1-480
KQ- 600DB	530×320×360	500×300×150	22.5	600	40-100	1000	20-80	1-480
KQ- 600DE	530×320×380	500×300×150	22.5	600	40-100	1000	20-80	1-480
KQ- 600DV	610×410×380	500×300×180	27	600	40-100	1000	20-80	1-480
KQ- 700DA	530×320×360	500×300×150	22.5	700	40-100	No	No	1-480
KQ- 700DB	530×320×360	500×300×150	22.5	700	40-100	1000	20-80	1-480
KQ- 700DE	530×320×380	500×300×150	22.5	700	40-100	1000	20-80	1-480
KQ- 700DV	610×410×380	500×300×180	27	700	40-100	1000	20-80	1-480
Supersonic frequency (KHz): 40 for all model
