DGG-9000(101)series of Stand-Drying and Air-Circulation Oven
Model
|
9030B(BD)
|
9070B(BD)
|
9140B(BD)
|
9240B(BD)
|
Chamber volume
|
31L
|
72L
|
136L
|
225L
|
Power supply
|
220V 50Hz
|
Temp.control range
|
Ambient temp. Rm.+10℃ - 300℃
|
Temp. fluctuation
|
±1℃
|
Dimension of working
chamber
|
300×300×350
|
400×400×450
|
450×550×550
|
500×600×750
|
Outside dimension
|
445×450×710
|
550×550×800
|
640×700×900
|
690×730×1100
|
Net weight
|
36KG
|
50KG
|
72.5KG
|
91KG
|
Heating power
|
940W
|
1240W
|
1740W
|
2290W
|
Shelf dimension
|
293×275
|
393×375
|
443×530
|
493×580
|
Shelves(supply/most)
|
2/4
|
2/4
|
2/4
|
2/5
|
* Dimension unit: mm, AD and BD mean programmable 10 bands temp. control.
|
