H2500R-2 High Speed Refrigerated Centrifuge
● Automatic rotor identification system
● LCD set data and operation data can display simultaneously.
● The operation time of centrifuge and rotor can be stored automatically. The service life of the rotor can be calculated automatically.
● The brushless direct drive motor with frequency conversion, imported from the USA ,has high start torque and short acceleration time.
● The centrifuge is equipped with the functions of imbalance, self lock lid, over temperature and over speed protection for the safety of the human and equipment.
● RCF value can be set directly for centrifuge operation without speed setting.
● The imported compressor (R404a) operation without Freon for the purpose of environment protection.
I. Specifications:
Max. speed: 25000r/min.
Max. RCF: 64800 x g (24 x 1.5/2ml 25000r/min)
Max capacity: 4 x 1000ml
Speed accuracy: ±30r/min.
Acc/Dec: The time of Acc/Dec can be set freely
The fast Acc time: 1 min. 30s (0 – 25000r/min.)
The fast Dec time: 1 min 40s (25000r/min. – 0)
Dimension of temperature setting: -20℃ - +40℃
Temperature accuracy: ±1℃
Refrigeration system: Non-Freon refrigeration system
Time range: 0 – 23h 59min.
Power supply: 220V 50Hz
Dimension: 710 x 820 x 950mm( L x W x H)
Weight: 290kg
